Pro9541WT From OKI
Introducing The Pro9541WT From OKI – A 5 Colour Digital Transfer Printer For The Production Of Customised Garments, Hard Surface Goods & More!
Introducing The Pro9541WT From OKI – A 5 Colour Digital Transfer Printer For The Production Of Customised Garments, Hard Surface Goods & More!
Broaden Your Revenue Opportunities
Extend your in-house printing capabilities with CMYK+White toner printing. Produce vibrant, full-color heat transfers for both light and dark textiles, hard surface goods, promotional merchandise, and more! Personalize almost anything from t-shirts and garments to ceramics, plastics, and metal – helping to grow your business by accessing lucrative new revenue streams.
Increase Your Production Output
Maximize your production using 329x483mm (A3+) sized sheets – saving time and money per job. Whether printing extra-large graphics or a full sheet of logos, the Pro9541WT will help you produce high quality, cost-effective transfers – no matter what size!
Brilliant White & True Black
This affordable 5 colors digital transfer printer has a low total cost of ownership and enables you to print brilliant color, opaque white, and true black…all at the same time, all in a single pass! The Pro9541WT provides users additional cost-savings with the ability to use true black (K) in place of composite black (CMY). A quick and easy alternative to screen and direct to garment printing, the Pro9541WT is perfect for the small-scale production of custom textiles and goods.
High Reliability & Performance
The Pro9541WT is easy to operate and does not require any daily maintenance or replacement kits. OKI is so confident about the reliability of the Pro9541WT that it comes with an industry-leading warranty and support package.
Printhead | Digital 5 LED Full-color Electrophotographic Printing Method |
Printing Resolution | 1200 x 1200 dpi (2 levels) 1200 x 600 dpi (16 levels) 600 x 600 dpi (2 levels) Physical dot pitch: 1200 dpi |
Warm-up Time | Approx. 50.0 seconds from power-on Approx. 35.0 seconds from power save |
First Print Out Time | Color: Approx. 8.0 seconds Mono: Approx. 8.0 seconds |
Print Speed | A4 (Landscape) 50 ppm color, 50 ppm mono A3 28 ppm color, 28 ppm mono |
Interface | 1000BASE-T/100BASE-TX/10BASE-T, USB 2.0 (High Speed) |
Protocol | TCP/IP, EtherTalk |
Printer Language | Adobe PostScript 3 |
Supported OS | Windows 10, Windows 10 x64, Windows 8.1, Windows 8.1 x64, Windows 8, Windows 8 x64, Windows 7, Windows 7 x64, Windows Server 2016, Windows Server 2012 R2, Windows Server 2012, Windows Server 2008 R2, Windows Server 2008, Windows Server 2008 x64, macOS 10.13, macOS 10.12, OS X 10.11, OS X 10.10 |
Memory (Std./Max.) | 2GB/2GB |
Hard Disk Drive | (Optional) 160 GB |
Font | PostScript emulation 136 fonts, PCL emulation 87 scalable fonts, 4 bitmap fonts |
Paper Size | 329x483mm (A3+), A3, A4, A5, A6, B4, B5, Letter, Legal 14, Legal 13.5, Legal 13, Executive, Tabloid (11″ x 17″), Tabloid extra (12″ x 18″), SRA3, SRA4, Statement, 8K, 16K, Custom Size: Width 64-330 mm x Length 89-1321 mm |
Paper Weight | Tray 1 : 52 – 320 gsm Multi-purpose tray : 52 – 360 gsm |
Input Capacity | Tray 1 : 530 sheets Multi-purpose tray : 300 sheets |
Output Capacity | Face Down : Max. 530 sheets Face Up : Max. 300 sheets |
Dimensions(WxDxH) | 699 x 665 x 640 mm |
Weight (includes supplies) | Approx. 111.0 kg |
Weight (not includes supplies) | Approx. 91.0 kg |
Operating Environment | Operating: 10 – 32 °C, 20 – 80 %RH Storage: 0 – 43 °C, 10 – 90 %RH No condensation |
Power Source | Single phase 220 – 240 VAC ±10%, 50/60 Hz ±2% |
Power Consumption | Operating: Max. 1,600W / Ave. 1,100W Idle: 40W Power Save: 34.0W Deep Sleep: 4.0W Auto-Off: 0.5W |
Safety & Environment Regulation | EMC-Directive, CE Mark, GS Mark |
Noise Level | Operating :Approx. 57 dBA Idle: < 34 dBA Power Save: < 30 dBA or Background level |
Duty Cycle | Recommended: 25,000 pages/month Maximum: 300,000 pages/month |
In the Box | Manuals, Starter toner cartridge x 5, Image Drum x 5, Power cable, DVD-ROM |
